36kV Vacuum Circuit Breaker Pole Assembly

Name: 36kV Vacuum Circuit Breaker Pole Assembly
Brand: H A Electrical And Switchgear

Get a Price/Quote

MOQ : 1 Piece

36kV Vacuum Circuit Breaker Pole Assembly Specification

Rated Current
630/1250 A

Thickness
6 to 15 mm (Epoxy Wall)

Cabinet Material
Compatible with Sheet Metal, CRCA Panel

Rated Operation Voltage
36 kV

Rated Insulation Voltage
40.5 kV

Connectivity Type
Busbar/Plug-in

Components
Vacuum Interrupter, Conductor, Housing, Flange

Base Material
Copper

Protection Level
Reinforced Insulation

Cover Material
Epoxy Resin

Protection Class
Class H

Way
Three Phase

Operating Voltage
36 kV AC

Current Rating
1250 A

Panel Type
Indoor/Outdoor Switchgear

Control System
Electromechanical/Manual

Cooling System
Air cooled

Features
High dielectric strength, Maintenance free, High mechanical endurance

Product Type
Vacuum Circuit Breaker Pole Assembly

Material
Epoxy Resin Encapsulated with Copper and Metal Components

Surface Finish
Smooth, Anti-Tracking

Standard
IEC 62271-100, IS 13118

Surface Color
Red (Brownish coating available)

Rated Voltage
36 kV

Frequency (MHz)
50 Hz

Maximum Output Current
Up to 1250 A

Dimension (L*W*H)
390 x 180 x 170 mm

Application
Medium Voltage Switchgear, Distribution Boards

IP Rating
IP4X

Breaking Capacity
Up to 25 kA

BIL (Basic Impulse Level)
170 kVp

Arc Quenching Medium
Vacuum

Mechanical Endurance
E2 Class (>10,000 Operations)

Contact Material
Copper Chromium alloy

Interrupter Type
Vacuum bottle hermetically sealed

Partial Discharge
10 pC (at 1.5 Ur)

Weight
8-14 kg per pole

Mounting Type
Horizontal/Vertical

Terminal Type
Bolt-on/Plug-in terminals

Storage Temperature Range
-40C to +55C

Ambient Temperature
-10C to +55C

Short Circuit Duration
3 seconds

Creepage Distance
>900 mm

Dielectric Withstand
95 kV (1 min, power frequency)

36kV Vacuum Circuit Breaker Pole Assembly Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

36kV Vacuum Circuit Breaker Pole Assembly About

Elevate your medium voltage switchgear with our crowning 36kV Vacuum Circuit Breaker Pole Assembly, offered at the lowest price and exclusive special rate for bulk orders. This valuable assembly features an impressive breaking capacity up to 25 kA and E2 class mechanical endurance exceeding 10,000 operations. Polished with a smooth, anti-tracking surface, the assembly uses epoxy resin encapsulation and copper chromium alloy contacts for reliability. Redeem unmatched operational excellence and reinforced insulation, compliant with IEC and IS standards for superior safety and performance in demanding applications.

Versatile Applications of 36kV Vacuum Circuit Breaker Pole Assembly

Used primarily for medium voltage switchgear, this assembly is essential in substations, power distribution boards, and industrial control panels. It finds broad application across both indoor and outdoor switchgear, efficiently handling rated currents up to 1250A. Its robust design ensures dependable performance in utilities, infrastructure, commercial complexes, and renewable energy grids, making it the preferred choice for reliable current interruption and protection. It supports horizontal or vertical mounting, offering flexible installation for tailored system requirements.

Delivery, Certification, & Payment Terms for 36kV Vacuum Circuit Breaker Pole Assembly

Our premium product enjoys a favorable market value and swift delivery within domestic and international markets. Each assembly is certified to the latest IEC and IS standards, ensuring authentic quality. Convenient payment terms are available, accommodating both private and public sector clients. Whether you are purchasing for large industrial projects or local utilities, we guarantee seamless processing and on-time dispatch, maximizing your operational timelines and optimizing your investment in a valuable power system solution.

FAQ's of 36kV Vacuum Circuit Breaker Pole Assembly:

Q: How is the 36kV Vacuum Circuit Breaker Pole Assembly installed?

A: The pole assembly is designed for horizontal or vertical mounting and supports easy installation with bolt-on or plug-in terminals, accommodating diverse panel and switchgear layouts.

Q: What are the key benefits of using a vacuum interrupter in this assembly?

A: The vacuum interrupter offers high dielectric strength, maintenance-free operation, and effective arc quenching, ensuring reliable circuit interruption with minimal partial discharge and long mechanical lifespan.

Q: When should I consider using this breaker pole assembly?

A: Use this assembly for applications up to 36kV in substations, distribution boards, or any medium voltage environment requiring high breaking capacity, mechanical endurance, and reinforced insulation for safety.

Q: Where can the 36kV Vacuum Circuit Breaker Pole Assembly be deployed?

A: It is suitable for both indoor and outdoor switchgear, making it ideal for utilities, industrial facilities, renewable energy installations, and infrastructure projects across various geographical locations.

Q: What is the certification standard for this assembly?

A: The assembly is certified as per IEC 62271-100 and IS 13118 standards, confirming its safety, performance, and quality for medium voltage switchgear applications.

Q: How does the special rate and lowest price offer benefit buyers?

A: Buyers can redeem exclusive pricing and maximize value, especially on bulk orders, ensuring cost-effectiveness without compromising on quality and compliance.
