VCB Panel

• Application
• Substation, Industrial, Distribution

• Base Material
• Other, Steel

• Cabinet Material
• Sheet Steel

• Components
• Vacuum Interrupter, Trip/Close Coil, Spring Mechanism

• Connectivity Type
• Cable Connection

• Control System
• Manual & Electrical

• Cooling System
• Air Cooled

• Cover Material
• Other, Steel

• Current Rating
• Up to 1250 A

• Dimension (L*W*H)
• 1200 x 800 x 1600 mm

• Display Type
• Other, Mechanical Indicator

• Features
• Compact Design, High Interruption Capacity, Arc Quenching, Fault Indication

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Metal Enclosure, Copper Contacts

• Maximum Output Current
• Up to 1250 A

• Operating Voltage
• 12 kV

• Panel Type
• Withdrawable Type

• Product Type
• Other, Vacuum Circuit Breaker

• Protection Class
• Class II

• Protection Level
• Other, Medium Voltage Protection

• Rated Current
• 630 A / 1250 A

• Rated Insulation Voltage
• 28 kV

• Rated Operation Voltage
• 12 kV

• Rated Voltage
• 12 kV

• Standard
• IEC 62271-100, IS 13118

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm (Enclosure) approx.

• Way
• 3 Phase

• Application
• Medium Voltage Power Distribution

• Base Material
• Other, Mild Steel Sheet

• Cabinet Material
• Powder Coated Steel

• Components
• Vacuum Interrupter, CT, PT, Control Wiring

• Connectivity Type
• Terminal Block

• Control System
• Manual/Automatic

• Cooling System
• Air Cooled

• Cover Material
• Mild Steel

• Current Rating
• 2500 A

• Dimension (L*W*H)
• 750 x 1200 x 2300 mm

• Display Type
• Other, Analog Meter

• Features
• High Breaking Capacity, Compact Design, Maintenance Free

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Mild Steel

• Maximum Output Current
• 2500 A

• Operating Voltage
• 33 kV

• Panel Type
• Indoor

• Product Type
• Other, Vacuum Circuit Breaker

• Protection Class
• Class I

• Protection Level
• Other, High Voltage

• Rated Current
• 2500 A

• Rated Insulation Voltage
• 38 kV

• Rated Operation Voltage
• 33 kV

• Rated Voltage
• 33 kV

• Standard
• IEC 62271-100

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm (panel)

• Way
• 3 Way

• Application
• Medium Voltage Indoor Switchgear, Industrial, Utility, Substation

• Base Material
• Other, Steel

• Cabinet Material
• Steel

• Components
• Vacuum interrupter, Spring Mechanism, Control Electronics

• Connectivity Type
• Wired

• Control System
• Manual / Motorized Spring Charging

• Cooling System
• Air-cooled

• Cover Material
• Other, Steel with powder coating

• Current Rating
• Up to 3150 A

• Dimension (L*W*H)
• Approx. 750 x 900 x 1650 mm

• Display Type
• Other, Mechanical Position Indicator

• Features
• Maintenance-free interrupter, High dielectric strength, Compact design, User friendly interface

• Frequency (MHz)
• 50 Hz / 60 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Vacuum Interrupter, Insulated Metal Housing

• Maximum Output Current
• Up to 3150 A

• Operating Voltage
• 12 kV / 17.5 kV / 24 kV

• Panel Type
• Withdrawable

• Product Type
• Other, Indoor Vacuum Circuit Breaker

• Protection Class
• Class E2, M2, C2 (IEC 62271-100)

• Protection Level
• Other, IP4X (front), IP2X (others)

• Rated Current
• 630 A / 1250 A / 2500 A / 3150 A

• Rated Insulation Voltage
• 28 kV / 38 kV (depending on model)

• Rated Operation Voltage
• Up to 24 kV

• Rated Voltage
• 12 kV / 17.5 kV / 24 kV

• Standard
• IEC 62271-100, IS 13118

• Surface Color
• Other, Grey / Red

• Surface Finish
• Powder Coated

• Thickness
• Sheet Metal: 2 mm (typical)

• Way
• 3 Phase

• Application
• Power Distribution/Transmission

• Base Material
• Stainless Steel

• Cabinet Material
• Stainless Steel

• Components
• Vacuum Interrupter, CT, PT

• Connectivity Type
• Terminal Lug

• Control System
• Manual and Motorized

• Cooling System
• Air Cooled

• Cover Material
• Stainless Steel

• Current Rating
• 1600A

• Dimension (L*W*H)
• 1700x1650x2450 mm

• Display Type
• Other, Mechanical Indication

• Features
• High Interrupting Capacity, Outdoor Operation, Low Maintenance

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP55

• Material
• Stainless Steel

• Maximum Output Current
• 1600A

• Operating Voltage
• 33 kV

• Panel Type
• Outdoor Panel

• Product Type
• Other, Outdoor Vacuum Circuit Breaker

• Protection Class
• Class I

• Protection Level
• IP55

• Rated Current
• 1600A

• Rated Insulation Voltage
• 38 kV

• Rated Operation Voltage
• 33 kV

• Rated Voltage
• 33 kV

• Standard
• IS 13118 / IEC 62271-100

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm

• Way
• 3 Way

• Application
• Medium Voltage Switchgear, Distribution Boards

• Base Material
• Other, Copper

• Cabinet Material
• Compatible with Sheet Metal, CRCA Panel

• Components
• Vacuum Interrupter, Conductor, Housing, Flange

• Connectivity Type
• Busbar/Plug-in

• Control System
• Electromechanical/Manual

• Cooling System
• Air cooled

• Cover Material
• Other, Epoxy Resin

• Current Rating
• 1250 A

• Dimension (L*W*H)
• 390 x 180 x 170 mm

• Features
• High dielectric strength, Maintenance free, High mechanical endurance

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Epoxy Resin Encapsulated with Copper and Metal Components

• Maximum Output Current
• Up to 1250 A

• Operating Voltage
• 36 kV AC

• Panel Type
• Indoor/Outdoor Switchgear

• Product Type
• Other, Vacuum Circuit Breaker Pole Assembly

• Protection Class
• Class H

• Protection Level
• Other, Reinforced Insulation

• Rated Current
• 630/1250 A

• Rated Insulation Voltage
• 40.5 kV

• Rated Operation Voltage
• 36 kV

• Rated Voltage
• 36 kV

• Standard
• IEC 62271-100, IS 13118

• Surface Color
• Other, Red (Brownish coating available)

• Surface Finish
• Other, Smooth, Anti-Tracking

• Thickness
• 6 to 15 mm (Epoxy Wall)

• Way
• Three Phase

• Application
• Medium Voltage Distribution

• Base Material
• Other, CRCA Sheet Steel

• Cabinet Material
• CRCA Sheet Steel

• Components
• Vacuum Interrupter, CT, PT, Relay, Busbars, ON/OFF/Trip Mechanism

• Connectivity Type
• Wired

• Control System
• Electro-mechanical

• Cooling System
• Air Natural Cooled

• Cover Material
• Other, Powder Coated Sheet Steel

• Current Rating
• 630A / 1250A

• Dimension (L*W*H)
• Approx. 800 mm x 1500 mm x 1200 mm

• Display Type
• Other, Mechanical Mimic Diagram

• Features
• High reliability, Low maintenance, Arc interruption in vacuum

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X (front), IP2X (others)

• Material
• Other, Metal-clad, Vacuum interlock

• Maximum Output Current
• Up to 1250A

• Operating Voltage
• 11kV AC

• Panel Type
• Indoor Metal-Clad

• Product Type
• Other, Vacuum Circuit Breaker

• Protection Class
• Class I

• Protection Level
• Other, High

• Rated Current
• 630A / 1250A

• Rated Insulation Voltage
• 12kV

• Rated Operation Voltage
• 11kV

• Rated Voltage
• 11kV

• Standard
• IS 13118 / IEC 62271-100

• Surface Color
• Other, Gray

• Surface Finish
• Powder Coated

• Thickness
• 3 mm enclosure

• Way
• 3 Phase

• Application
• Medium voltage power distribution

• Base Material
• Other, Mild Steel (MS)

• Cabinet Material
• CRCA sheet

• Components
• Vacuum Interrupters, CTs, PTs, Relays

• Connectivity Type
• Bus bar connection

• Control System
• Microprocessor/relay based

• Cooling System
• Air cooled

• Cover Material
• Other, Powder coated steel

• Current Rating
• 630/1250 A

• Dimension (L*W*H)
• 900 mm x 1100 mm x 2200 mm

• Display Type
• Other, Analog/digital meters

• Features
• Compact design, Draw-out type, Manual/Motorized operation, Safety interlocks

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Metal clad

• Maximum Output Current
• 1250 A

• Operating Voltage
• 11,000 V

• Panel Type
• Indoor/outdoor type

• Product Type
• Other, HT Vacuum Circuit Breaker

• Protection Class
• Class F

• Protection Level
• Other, Medium voltage protection

• Rated Current
• 630/1250 A

• Rated Insulation Voltage
• 12 kV

• Rated Operation Voltage
• 11 kV

• Rated Voltage
• 11 kV

• Standard
• IS 13118 / IEC 62271-100

• Surface Color
• Other, Grey

• Surface Finish
• Other, Epoxy powder coated

• Thickness
• 3 mm (enclosure body)

• Way
• 3 phase

• Application
• Industrial Power Distribution

• Base Material
• Other, Steel

• Cabinet Material
• CRCA Steel

• Components
• Vacuum Interrupter, Control Circuit, CT/PT, Shunt Release

• Connectivity Type
• Busbar/Terminal

• Control System
• Spring/Electromagnetic

• Cooling System
• Natural Air

• Cover Material
• Other, Epoxy Resin

• Current Rating
• 1250A

• Dimension (L*W*H)
• 800mm x 900mm x 2200mm

• Display Type
• Other, Mechanical On/Off Indicator

• Features
• Maintenance Free, Compact Design, Arc Resistant

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, High-strength epoxy resin, Copper Contacts

• Maximum Output Current
• 1250A

• Operating Voltage
• 11kV AC

• Panel Type
• Indoor/Outdoor

• Product Type
• Other, Vacuum Circuit Breaker

• Protection Class
• Class II

• Protection Level
• Other, Medium Voltage

• Rated Current
• 1250A

• Rated Insulation Voltage
• 28kV

• Rated Operation Voltage
• 12kV

• Rated Voltage
• 11kV

• Standard
• IEC 62271-100, IS 13118

• Surface Color
• Other, Light Grey

• Surface Finish
• Powder Coated

• Thickness
• 2.5 mm (Panel)

• Way
• 3 Phase

• Application
• Power Distribution

• Base Material
• Galvanized Steel

• Cabinet Material
• Galvanized Steel

• Components
• Vacuum Interrupter, CT, PT

• Connectivity Type
• Terminal Connectors

• Control System
• Electro-mechanical

• Cooling System
• Natural Air Cooled

• Cover Material
• Other, Epoxy Resin

• Current Rating
• 1250 A

• Dimension (L*W*H)
• 1850 x 850 x 2300 mm

• Display Type
• Other, Analog Position Indicator

• Features
• Outdoor, Arc Quenching, Maintenance Free

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP55

• Material
• Other, Epoxy Resin & Metal

• Maximum Output Current
• 1250 A

• Operating Voltage
• 33 kV

• Panel Type
• Outdoor

• Product Type
• Other, Outdoor Vacuum Circuit Breaker

• Protection Class
• Class H

• Protection Level
• IP55

• Rated Current
• 1250 A

• Rated Insulation Voltage
• 38 kV

• Rated Operation Voltage
• 33 kV

• Rated Voltage
• 33 kV

• Standard
• IEC 62271-100

• Surface Color
• White

• Surface Finish
• Other, Weatherproof Coated

• Thickness
• 6 mm (Cabinet)

• Way
• Triple Pole

• Application
• Outdoor Electrical Distribution

• Base Material
• Other, Steel

• Cabinet Material
• Sheet Steel

• Components
• Vacuum Interrupter, CTs, PTs, Relays

• Connectivity Type
• Hardwired/Terminal Connections

• Control System
• Electro-Mechanical

• Cooling System
• Natural Air Cooled

• Cover Material
• Other, Epoxy Coated Steel

• Current Rating
• 1250 A

• Dimension (L*W*H)
• 1380 mm x 1100 mm x 2200 mm

• Display Type
• Other, Analog & LED Indicators

• Features
• Arc Quenching Vacuum Interrupter, Maintenance-Free, Compact Design

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP55

• Material
• Other, Vacuum Interrupter, Epoxy Resin, Sheet Metal, Copper, Silver-Plated Contacts

• Maximum Output Current
• 1250 A

• Operating Voltage
• 12 kV

• Panel Type
• Floor Mounted

• Product Type
• Other, Outdoor Vacuum Circuit Breaker

• Protection Class
• Class II

• Protection Level
• IP55

• Rated Current
• 1250 A

• Rated Insulation Voltage
• 28 kV (Power Frequency withstand)

• Rated Operation Voltage
• 12 kV

• Rated Voltage
• 12 kV

• Standard
• IS/IEC 62271-100

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm enclosure

• Way
• 3 Phase

• Application
• Industrial/Power Utility

• Base Material
• Other, Mild Steel base

• Cabinet Material
• Stainless Steel

• Components
• VCB, CT, PT, Busbar

• Connectivity Type
• Hardwired

• Control System
• Semi Automatic

• Cooling System
• Natural Air Cooling

• Cover Material
• Stainless Steel

• Current Rating
• 1000A

• Dimension (L*W*H)
• 2200x800x1600 mm

• Display Type
• Other, Analog meters

• Features
• Arc Proof, Interlocked, Maintenance Free

• Frequency (MHz)
• 50/60 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Stainless Steel (SS)

• Maximum Output Current
• 1000A

• Operating Voltage
• 11 kV

• Panel Type
• Indoor

• Product Type
• Other, Vacuum Circuit Breaker Panel

• Protection Class
• Class I

• Protection Level
• Other, High

• Rated Current
• 1000A

• Rated Insulation Voltage
• 12 kV

• Rated Operation Voltage
• 11 kV

• Rated Voltage
• 11 kV

• Standard
• IEC 62271-200

• Surface Color
• Other, Light Grey

• Surface Finish
• Powder Coated

• Thickness
• 2 mm

• Way
• 3-Way

• Application
• Distribution & Protection of Electrical Networks

• Base Material
• Other, Sheet Metal

• Cabinet Material
• High-Grade Sheet Steel

• Components
• Vacuum Interrupter, Spring Mechanism, Auxiliary Contacts

• Connectivity Type
• Copper Busbar Connections

• Control System
• Manual & Motorized Mechanisms

• Cooling System
• Air Cooled

• Cover Material
• Other, Epoxy Resin

• Current Rating
• 1250 A

• Dimension (L*W*H)
• 580 mm x 800 mm x 1450 mm

• Display Type
• Other, Mechanical Indication Window

• Features
• Maintenance Free, Long Service Life, High Short Circuit Withstand

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Vacuum Interrupter, Epoxy Resin, Copper

• Maximum Output Current
• 1250 A

• Operating Voltage
• 12 kV

• Panel Type
• Metal Clad

• Product Type
• Other, Medium Voltage Vacuum Circuit Breaker

• Protection Class
• Class H

• Protection Level
• Other, IP4X

• Rated Current
• 1250 A

• Rated Insulation Voltage
• 28 kV

• Rated Operation Voltage
• 12 kV

• Rated Voltage
• 12 kV

• Standard
• IEC 62271-100, IS 13118

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm

• Way
• Three Pole

• Application
• Commercial, Industrial substations

• Base Material
• Other, Sheet steel

• Cabinet Material
• Powder-coated steel

• Components
• Breaker, CT, PT, relays

• Connectivity Type
• Panel mount terminal

• Control System
• Manual/Electrical

• Cooling System
• Natural air cooling

• Cover Material
• Mild Steel

• Current Rating
• 1250A

• Dimension (L*W*H)
• 900x1000x2250 mm

• Display Type
• Other, Analog/LED indicators

• Features
• High interrupting capacity, compact design

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, High quality epoxy resin

• Maximum Output Current
• 1250A

• Operating Voltage
• 440V

• Panel Type
• Vacuum circuit breaker

• Product Type
• Other, Indoor Vacuum Circuit Breaker

• Protection Class
• Class II

• Protection Level
• Other, Indoor

• Rated Current
• 1250A

• Rated Insulation Voltage
• 12 kV

• Rated Operation Voltage
• 11 kV

• Rated Voltage
• 11 kV

• Standard
• IEC 62271-100

• Surface Color
• Other, Light grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm cabinet

• Way
• 3 way

• Application
• Medium Voltage Distribution

• Base Material
• Other, Metal Sheet

• Cabinet Material
• CRCA Steel

• Components
• Vacuum Interrupter, Spring Mechanism, CT, PT

• Connectivity Type
• Cable/ Busbar

• Control System
• Manual & Motor Operated

• Cooling System
• Air Cooled

• Cover Material
• Other, Epoxy Resin

• Current Rating
• 630 A / 1250 A

• Dimension (L*W*H)
• 900 x 1000 x 2100 mm

• Display Type
• Other, Analog/LED Indicator

• Features
• Arc Quenching, Maintenance Free, Compact Design, High Mechanical Strength

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Epoxy Resin, Metal

• Maximum Output Current
• 1250 A

• Operating Voltage
• 11,000 V

• Panel Type
• Indoor/Outdoor

• Product Type
• Other, Vacuum Circuit Breaker

• Protection Class
• Class I

• Protection Level
• Other, High

• Rated Current
• 630 A / 1250 A

• Rated Insulation Voltage
• 12 kV

• Rated Operation Voltage
• 11 kV

• Rated Voltage
• 11 kV

• Standard
• IEC 62271-100

• Surface Color
• Other, Grey

• Surface Finish
• Powder Coated

• Thickness
• 3 mm

• Way
• Three Phase

• Application
• Power Distribution

• Base Material
• Other, CRCA Sheet

• Cabinet Material
• CRCA Steel

• Components
• Vacuum Interrupter, CT, PT, Relays, Bus Bar

• Connectivity Type
• Fixed or Withdrawable

• Control System
• Electro-Mechanical

• Cooling System
• Air Cooled

• Cover Material
• Other, Epoxy Resin

• Current Rating
• 25 kA

• Dimension (L*W*H)
• 720x1030x2040 mm

• Display Type
• Analog

• Features
• Arc Quenching, Maintenance Free, Compact Design

• Frequency (MHz)
• 50 Hz

• IP Rating
• Other, IP4X

• Material
• Other, Metal, Epoxy Resin

• Maximum Output Current
• 25 kA

• Operating Voltage
• 12 kV

• Panel Type
• Indoor

• Product Type
• Other, Vacuum Circuit Breaker

• Protection Class
• Class B

• Protection Level
• Other, High

• Rated Current
• 1250 A

• Rated Insulation Voltage
• 28 kV

• Rated Operation Voltage
• 12 kV

• Rated Voltage
• 12 kV

• Standard
• IS/IEC 62271-100

• Surface Color
• Other, Gray

• Surface Finish
• Powder Coated

• Thickness
• 3 mm

• Way
• 3 Phase
