ABB SafeRing XT Ring Main Unit

Name: ABB SafeRing XT Ring Main Unit
Brand: H A Electrical And Switchgear

Get a Price/Quote

MOQ : 1 Piece

ABB SafeRing XT Ring Main Unit Specification

Cover Material
Powder Coated Steel

Way
2, 3, 4, 5, or 6 Ways

Current Rating
Up to 630 A

Thickness
2 mm (Panel Thickness)

Protection Level
Internal arc classified, up to AFLR 20 kA/1s

Cabinet Material
Corrosion Resistant Steel

Protection Class
Class II

Features
Compact Design, Maintenance-Free, Modular, High Safety

Control System
Manual and Motorized Option

Cooling System
Self-Air Cooled

Components
Vacuum Circuit Breaker, Earthing Switch, Load Break Switch, Fuse Unit

Rated Current
Up to 630 A

Operating Voltage
Up to 24 kV

Base Material
Galvanized Sheet

Rated Insulation Voltage
28 kV

Rated Operation Voltage
12/24 kV

Panel Type
Modular GIS Panel

Connectivity Type
SCADA/Digital Ready

Product Type
Gas Insulated Ring Main Unit

Material
Stainless Steel, Galvanized Steel and High-Quality Insulated Compounds

Surface Finish
Powder Coated

Standard
IEC 62271-200, IEC 60265

Surface Color
Light Grey (RAL 7035)

Rated Voltage
12 kV

Frequency (MHz)
50/60 Hz

Maximum Output Current
630 A

Dimension (L*W*H)
650 x 800 x 1650 mm

Application
Medium Voltage Distribution Networks

IP Rating
IP67 (SF6 Tank), IP4X (External Surface)

Display Type
Mechanical Indication Windows

Insulation Medium
SF6 Gas (Sealed for life, Hermetically Sealed Tank)

Weight
Approx. 220 to 400 kg (depending on configuration)

Maintenance
Operation for the lifetime without SF6 gas refilling or maintenance

Integration
Fully compatible with remote monitoring and control systems

Gas Type
SF6 Insulated

Interlock Devices
Integrated Key and Padlocking

Internal Arc Classification
AFLR, 20 kA, 1s

Rated Short-Time Withstand Current
20 kA/3 s

Operating Temperature Range
-25C to +55C

Standards Compliance
Designed and tested according to IEC and national standards

Relative Humidity
Up to 95% non-condensing

Earthing Switch Making Capacity
50 kA Peak

Type of Cable Termination
Heat Shrink or Cold Applied Cable Termination

Operating Altitude
Up to 2000 m

ABB SafeRing XT Ring Main Unit Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

ABB SafeRing XT Ring Main Unit About

Discover the ABB SafeRing XT Ring Main Unit, a resplendent solution engineered for elite medium voltage distribution networks. This modular GIS panel, renowned for favorable reviews and meritorious reliability, is competitively priced and now available at a reduced price for select configurations. Featuring hermetically sealed SF6 gas insulation, its operation is virtually maintenance-free for life. With high safety, robust stainless-steel construction, and built-in remote monitoring compatibility, the SafeRing XT is an exceptional choice for exporters, manufacturers, suppliers, and traders seeking unrivaled performance and value within India's power infrastructure.

Applications and Installation Surface

The ABB SafeRing XT Ring Main Unit is optimal for deployment in medium voltage distribution networks across industrial, commercial, and utility environments. Its application media is SF6 gas-sealed for life within a rustproof enclosure-providing steadfast insulation. Designed for easy integration on internal substation surfaces, this modular unit meets the needs of both new installations and upgrades, owing to its compact footprint and superior site adaptability.

Timely Delivery, Robust Capability, and Certifications

Your ABB SafeRing XT purchase, upon order confirmation, is handed over within an industry-leading delivery timeframe suitable for project requirements. With a premium supply ability for multiple configurations, the unit is charged with internationally recognized certifications, including IEC 62271-200 and IEC 60265 compliance. Customers gain reassurance from ABB's rigorous quality standards, ensuring secure, certified functionality for critical infrastructures.

FAQ's of ABB SafeRing XT Ring Main Unit:

Q: How does the ABB SafeRing XT ensure safety during operation?

A: The SafeRing XT includes integrated key and padlocking interlock devices, is internally arc-classified (AFLR up to 20 kA/1s), and features hermetically sealed SF6 tanks for maximum safety under various operating conditions.

Q: What are the main benefits of the maintenance-free SF6 insulation system?

A: This system eliminates the need for periodic gas refilling or maintenance, providing a sealed, lifetime service solution that reduces operational costs and increases reliability in demanding environments.

Q: Where can the ABB SafeRing XT be used most effectively?

A: It is ideal for medium voltage distribution within industrial complexes, commercial buildings, and utility substations, supporting both indoor substation panels and outdoor enclosures due to its robust protection and corrosion resistance.

Q: What is the process for integrating the SafeRing XT with remote monitoring systems?

A: The unit is SCADA and digital ready, allowing straightforward digital integration via mechanical indication windows and connectivity options to monitor and control network status in real-time.

Q: When can customers expect the ABB SafeRing XT to be delivered after placing an order?

A: Delivery time is tailored to project demands, with efficient handover ensured thanks to ABB's premium supply and distribution network capabilities.
