Prefabricated Compact Substation

Name: Prefabricated Compact Substation
Brand: H A Electrical And Switchgear

Get a Price/Quote

MOQ : 1 Piece

Prefabricated Compact Substation Specification

Load Loss
As per IEC/IS Standards

Voltage Booster Type
Step-down

Low Voltage
415 V / 433 V

Capacity
200 kVA to 2500 kVA

Dimension (L*W*H)
Customized (typically 300023002400 mm)

Rated Voltage
11 kV / 33 kV

Operating Temperature
-25C to +50C

Cooling Type
ONAN (Oil Natural Air Natural)

Coil Material
High-grade Copper/Aluminum

High Voltage
Up to 36 kV

Standard
IEC 62271-202, IS 14786

Product Type
Prefabricated Compact Substation

Material
Mild Steel & Galvanized Steel

Output
Up to 2500 kVA

Frequency (MHz)
50 Hz

Efficiency
Up to 99%

Phase
Three Phase

Usage
Outdoor electrical distribution

Coil Structure
Copper/Aluminum Wound

Coil Number
Three

Power Scope
Distribution and Power Supply

Weight
Depends on rating (approx. 1.5 to 3 metric tons)

Insulation Class
Class F / H

Mounting Type
Outdoor Floor Mounted

Transformer Type
Oil Immersed/ Dry Type

Earthing
Double Earthing Provided

Enclosure Protection
IP55

Ambient Temperature Range
-25C to +50C

Cooling Medium
Oil or Air

Connections
Copper/Aluminum Busbars

Surface Finish
Powder Coated/Hot Dip Galvanized

Fire & Vermin Resistant
Yes

Protection Devices
HT & LT Circuit Breakers, Fuses, Relays

Prefabricated Compact Substation Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Pieces Per Month

Delivery Time
5-7 Days

Main Domestic Market
All India

About Prefabricated Compact Substation

Unlock unassailable reliability and first-string performance with our Prefabricated Compact Substation, crafted for valorous energy distribution. Engineered with an affordable and reduced footprint, it integrates enclosure protection (IP55), robust oil-immersed or dry-type transformer options, and sophisticated HT & LT circuit breakers, fuses, and relays. The double earthing and fire-resistant construction deliver uncompromising safety. Powder-coated or hot dip galvanized finishes provide enduring durability, while high-efficiency design reaches up to 99%. Tailored for outdoor use, its modular and resilient build ensures optimum capacity (200-2500 kVA) for modern power demands.

Engineered for Industrial Prowess: Applications and Features

Our Prefabricated Compact Substation suits diverse plant applications-ideal for power distribution in manufacturing, process industries, and infrastructure sites. Purpose-built for outdoor usage, its robust mild steel and galvanized steel housing ensures long-lasting performance. Secure powder-coated or hot-dip galvanized finishes offer superior protection, while the enclosure is fire and vermin resistant. Available in multiple transformer types (oil-immersed/dry), this substation exemplifies valorous design focused on strength and safety.

Domestic Reach & Shipping: Market Accessibility and Delivery

Serving the vast Indian domestic market, our substations offer competitive asking prices without compromising quality. Goods are shipped from key FOB ports with prompt delivery timelines to ensure customer satisfaction. Buyers can request sample availability to assess product value and finish before large-scale procurement. With proven market value and tailored solutions, we cater to top-class industrial requirements with unwavering reliability and efficient service.

FAQ's of Prefabricated Compact Substation:

Q: How does the enclosure's IP55 rating enhance outdoor usage?

A: The IP55 enclosure rating provides unassailable dust and water protection, making the substation suitable for outdoor installations in challenging environments, ensuring reliable operation under adverse weather conditions.

Q: What transformer types and cooling mediums are available in this compact substation?

A: You can choose between oil-immersed and dry-type transformers, paired with oil or air cooling mediums (ONAN), ensuring optimal energy efficiency and performance for various industry requirements.

Q: Where can this prefabricated substation be installed?

A: This substation is designed for outdoor floor mounting, making it ideal for manufacturing plants, infrastructure projects, and any site requiring reliable power distribution in three-phase systems.

Q: What are the safety and protection features integrated into the substation?

A: The substation boasts double earthing, HT & LT circuit breakers, fuses, relays, and fire/ vermin resistance, ensuring valorous protection for personnel and equipment against electrical and environmental hazards.

Q: How does the ordering and shipping process work for domestic clients?

A: Domestic clients in India can place orders directly with the manufacturer, trader, or supplier. Goods are shipped FOB from designated ports, with samples available for review prior to larger shipments.

Q: What is the operating efficiency and standard compliance of this product?

A: The substation delivers up to 99% efficiency, adhering to IEC 62271-202 and IS 14786 standards, ensuring long-term, first-string performance in critical power applications.
