Unitized Substation

• Capacity
• 200 kVA to 2500 kVA

• Coil Material
• Other , High-grade Copper/Aluminum

• Coil Number
• Other, Three

• Coil Structure
• Other, Copper/Aluminum Wound

• Cooling Type
• ONAN (Oil Natural Air Natural)

• Dimension (L*W*H)
• Customized (typically 300023002400 mm)

• Efficiency
• Up to 99%

• Frequency (MHz)
• 50 Hz

• High Voltage
• Up to 36 kV

• Load Loss
• As per IEC/IS Standards

• Low Voltage
• 415 V / 433 V

• Material
• Mild Steel & Galvanized Steel

• Operating Temperature
• -25C to +50C

• Output
• Up to 2500 kVA

• Phase
• Three Phase

• Power Scope
• Distribution and Power Supply

• Product Type
• Other, Prefabricated Compact Substation

• Rated Voltage
• 11 kV / 33 kV

• Standard
• IEC 62271-202, IS 14786

• Usage
• Outdoor electrical distribution

• Voltage Booster Type
• Other, Step-down

• Weight
• Depends on rating (approx. 1.5 to 3 metric tons)

• Capacity
• 100 kVA

• Coil Material
• Other , Copper

• Coil Number
• Other, Primary & Secondary

• Coil Structure
• Other, Dry/Cast resin

• Cooling Type
• ONAN (Air Natural)

• Dimension (L*W*H)
• 2200 x 1600 x 1850 mm

• Efficiency
• High efficiency

• Frequency (MHz)
• 50

• High Voltage
• 11 kV

• Load Loss
• As per IS standard

• Low Voltage
• 0.433 kV

• Material
• Copper

• Operating Temperature
• -20C to +50C

• Output
• 433 V

• Phase
• Three Phase

• Power Scope
• 100 kVA

• Product Type
• Other, Compact Substation

• Rated Voltage
• 11/0.433 kV

• Standard
• IS 14786/IEC 61330

• Usage
• Outdoor power distribution

• Voltage Booster Type
• Other, Step-down

• Weight
• Approx. 1800 kg

• Capacity
• 500kVA

• Cooling Type
• Air Cooled

• Material
• Copper

• Phase
• Three Phase
